AMB 2026 | Reagle Sensing Showcases Full-Scenario Sensing Solutions with Precision Innovation in Stuttgart

AMB斯圖加特匯聚全球機床行業頂尖技術與專業目光。作為工業自動化的發源地，德國市場對精度、可靠性與長期穩定性的標準極為嚴苛——AMB正是歐洲高端機床與運動控制產業鏈的權威舞臺。

AMB Stuttgart: where German engineering's exacting standards for precision and reliability make it Europe's definitive stage for high-end machine tool and motion control innovation.

銳鷹傳感以近兩千萬臺設備全球驗證的實力，攜光、磁、感、力四大技術平臺解決方案亮相6號館6B53展位，并面向高端數控機床提供覆蓋進給軸、主軸與四/五軸轉臺的全場景傳感解決方案。

Backed by nearly 20 million devices in the field worldwide, Reagle Sensing presents its optical, magnetic, inductive, and force sensing platforms at Booth 6B53 (Hall 6), delivering full-scenario sensing solutions for high-end CNC machines—spanning feed axes, spindles, and 4/5-axis rotary tables.

方案適配靈活，多協議兼容，精準匹配高精度、高動態響應需求，助力實現更優的加工表面質量與良率；同時具備出色的抗振、抗污、抗干擾能力，顯著降低非計劃停機與故障率，保障設備長期運行下的精度穩定性。

Multi-protocol compatibility and flexible adaptation deliver superior surface quality and yield, while excellent vibration, contamination, and interference resistance reduce unplanned downtime and ensure long-term precision stability.

01 適用于進給軸的直線編碼器 Linear Encoders for Feed Axes

傳統半閉環控制依賴滾珠絲杠，易受熱變形、反向間隙影響。SCIH100封閉式絕對值直線感柵尺直接測量滑座位置，構建全閉環控制，從源頭消除傳動誤差。

Traditional semi-closed-loop control relies on ball screws, prone to thermal deformation and backlash. The SCIH100 enclosed absolute linear inductive scale measures slide position directly, enabling full closed-loop control and eliminating transmission errors at the source.

核心亮點：電磁感應，無懼油污與水汽

Key Highlight: Electromagnetic Induction — Impervious to Oil and Moisture

與光柵尺依賴潔凈空氣不同，SCIH100采用電磁感應檢測原理，從根本上擺脫了對潔凈環境的依賴。相較于光柵尺，SCIH100具備更優異的耐油、耐水性能，耐污性與可靠性顯著提升——在冷卻液飛濺、鐵屑彌漫的真實車間環境中，依然保持穩定輸出，讓精度不再因污染而"打折"。

Unlike optical scales that demand pristine air, the SCIH100 detects via electromagnetic induction—freeing itself from clean-environment constraints. With superior oil, water, and dirt resistance, it stays accurate and stable amid coolant splash and metal chips, so contamination never compromises precision.

堅固防護結構 Robust Protective Structure

優化傳感器形態與高防護等級外殼設計，配合防塵密封與耐冷卻液材料，適應各類嚴苛工況。

Optimized sensor design and a high-protection-rating housing, combined with dust-proof seals and coolant-resistant materials, ensure suitability for a wide range of harsh operating conditions.

納米級測量精度 Nanometer-level measurement accuracy

基于自主研發的電磁感應信號處理技術，實現高達50nm分辨率的精密位置反饋。

Based on proprietary electromagnetic induction signal processing technology, it provides precise position feedback with a resolution of up to 50 nm.

便捷可靠安裝Convenient and Reliable Installation

兼容行業標準多點安裝方式，具備高抗振、抗沖擊特性，安裝調試更便捷。

Compatible with industry-standard multi-point mounting configurations, featuring high resistance to vibration and shock for easier installation and commissioning.

02 適用于四/五軸轉臺的編碼器 Encoders for 4- and 5-axis rotary tables

KIH系列中空感柵編碼器專為機床四/五軸轉臺設計，采用非接觸式電感技術，具有高動態響應和強環境適應性，在油污、水汽、振動等惡劣工況下依然穩定運行，精度不受影響。

The KIH hollow-shaft encoder is purpose-built for 4/5-axis machine tool rotary tables. Its non-contact inductive technology delivers high dynamic response and maintains precision despite oil, moisture, and vibration.

KIH系列中空感柵編碼器 KIH Series Hollow Shaft Encoders

最高分辨率26bit，絕對定位精度≤±5角秒，重復精度≤±1.5角秒；安裝容限大，定子偏心4.4絲以內或轉子偏心6絲以內，對精度無影響，支持激光干涉儀一鍵補償；IP65防護，涉水精度不受影響，天然抗電磁干擾；提供多種尺寸，適配精密機床到大型加工中心各類轉臺。

With a maximum resolution of 26 bits, absolute positioning accuracy of ≤ ±5 arcseconds, and repeatability of ≤ ±1.5 arcseconds, the sensor features generous installation tolerances—stator eccentricity within 0.044 mm or rotor eccentricity within 0.06 mm has no impact on accuracy—and supports one-click compensation via laser interferometer. With IP65 protection, accuracy remains unaffected even in wet conditions, and the sensor is inherently immune to electromagnetic interference. Available in a wide range of sizes, it adapts to rotary tables of all kinds, from precision machine tools to large-scale machining centers.

HON絕對值圓光柵HON Absolute Circular Encoder

采用一體式不銹鋼結構，外刻真正絕對值單碼道，搭配SONA36讀頭抗污出色；柵距30μm、26bit分辨率0.019角秒，精度滿足精密轉臺等嚴苛場景；輕薄低慣量設計零負擔嵌入高速系統，多規格兼容主流標準，讓精密測量在真實工況下穩定如初。

Featuring a one-piece stainless steel structure with a true-absolute single code track engraved on the outer ring, paired with the SONA36 readhead for outstanding contamination resistance. With a 30 μm grating pitch and 26-bit resolution of 0.019 arcseconds, its accuracy meets the demands of demanding applications such as precision rotary tables. The thin, lightweight, low-inertia design integrates into high-speed systems with zero burden, while multiple specifications are compatible with mainstream standards—keeping precision measurement stable as ever under real-world operating conditions.

03 適用于進給軸的旋轉編碼器 Rotary Encoder for Feed Axes

為解決傳統編碼器因電池老化、漏液或斷電導致數據丟失、頻繁維護的痛點，銳鷹傳感推出無電池機械多圈系列，采用獨特的機械多圈計數結構，斷電后永久保持位置信息，真正實現零維護、高可靠、長壽命。

To eliminate data loss and frequent maintenance caused by battery degradation or power failure, Reagle's battery-free mechanical multi-turn encoders permanently retain position without battery power—truly maintenance-free, highly reliable, and long-lasting.

SROA48整體機械多圈絕對值編碼器

SROA48 Integral Mechanical Multi-Turn Absolute Encoder

無電池機械多圈，免電池盒、終生免維護，杜絕位置丟失與重新調刀。25位高精度，配合高精補償算法，伺服動態響應更優，加工光潔度更佳。高剛性、高響應、高定位精度，高度僅29mm，軸向空間節省20%。

Battery-free mechanical multi-turn, lifetime maintenance-free, eliminates position loss and tool re-alignment. 25-bit high precision with compensation algorithms for superior servo dynamic response and surface finish. High rigidity, high response, high positioning accuracy. Height: 29mm, 20% axial space saving.

SROA105十字聯軸機械多圈絕對值編碼器

SROA105 Cross-Shaft Mechanical Multi-Turn Absolute Encoder

機械多圈技術，免電池維護隔熱；允許轉動軸偏擺及軸竄誤差大；集成電機后蓋設計，兼容安裝接口，維護便利。

Mechanical multi-turn, battery-free, heat-insulated. Accommodates large shaft runout and axial play. Integrated motor rear cover, compatible mounting interface for easy maintenance.

04適用于主軸的編碼器 Encoders for Spindles

HME齒輪環編碼器HME Gear Ring Encoder

低速度波動和高信號質量，讀頭IP68防護等級，適用于惡劣環境；非接觸式，免保養無磨損，提供128/256/384/512多種齒輪可選。

Low-speed fluctuations and high signal quality; the read head features an IP68 protection rating, making it suitable for harsh environments; non-contact, maintenance-free, and wear-free; available with a variety of gear options: 128, 256, 384, and 512.

ERO正余弦編碼器 ERO Sine-Cosine Encoder

兼容性強，高可靠性、高防護性，支持通訊型、模擬量。

High compatibility, high reliability, and high protection; supports communication and analog signals.

德國斯圖加特國際金屬加工展覽會（AMB 2026）開幕在即，與銳鷹傳感共話機床行業的前沿應用，探索傳感技術如何為高端機床注入"精度靈魂"，攜手推動機床行業的智造革新與精度革命！

AMB 2026 is about to open. Join Reagle Sensing to explore how sensor technology empowers high-end machine tools with the "soul of precision." Visit us at Hall 6, Booth 6B53.

敬請蒞臨銳鷹傳感展位6號展館6B53，共赴這場行業盛會！

We cordially invite you to visit the Reagle Sensing booth at Hall 6, Booth 6B53, and join us for this industry event!
